Micro DC is a unified infrastructure, which fully integrates power, cooling, security and monitoring systems in one secured enclosure. Micro DC delivers instant IT capacities without any construction work or extensive site preparations. Just add your IT equipment to this prefabricated and Configured Data Centre Solution!
A safe and highly accessible IT environment is the foundation of practically any business today. Micro DC has been developed as a suitable foundation for consolidating IT infrastructure.
A modern, prefabricated alternative to a server room.
Pre-manufactured and pre-tested prior to delivery and deployment to client site, minimising any construction and other preparatory work.
MDC – as the name suggests – “Everything in a single box”!
Typical usual / optional elements comprises of - but not limited to the list hereunder:
(Useable Height Reduces)
(Full Useable Height)
An IP54 level ingress protection rack with fully secured front door, rear door and side panels.
Rack Doors are integrated with Biometric + Prox-card based access control and Digital swing-handle lock (Unlike Electromagnetic Lock). Biometric reader is equipped with patented fake fingerprint detection technology and complete remote management over IP.
Self-contained Rack with cooling units having EC fans for better air distribution efficiency and lower energy consumption. Thus, improving overall power utilisation effectiveness.
Rack UPS and Vertical / Zero U Rack Power Distribution System (PDU) are fully integrated and offer much robust performance - increasing overall reliability and durability.
It is rightly said, you can’t manage what you don’t measure. Health of computing equipment will define the equipment durability, efficiency and performance. So, here we monitor power and environment parameters like: Voltage (V), Current (A), Power (KW), Energy (KWh), Temperature, Humidity, Door Status, Smoke Detector and WLD.
A Micro Data Centre enables to achieve – swift operation management, cooling optimisation, ideal PUE, Uptime and Durability.
Main Advantages
Plenty of space for the cable management and ease of servicing. These IP54 Rated Racks offer highly efficient space management.
Choice of Tailored PDU from conventional PDU’s to switched or simply metered intelligent PDU’s with optional Environmental – Door – WLD – Fire and other sensors integrated over IP.
Offering can be made with UPS systems & Battery Back-Up. This can be internal or external to rack and capacity + Back-Up in line with your requirement.
In-Rack Mounted or Side Mounted Cooling units in variety of sizes ranging from 3,500W to 18,000W with optional RH controlled Units in DX / CW Versions.
Optional RMU offer gamut of sensors and monitoring means to manage the operational side of the rack much in line with your requirement.
Starting from simple mechanical lock to Pin-Pad or Prox Card and Biometric access control with / without IP connectivity to suit your requirement.
Various levels of solution are available ranging from simple fire detection to rack based VESDA and FAP with Suppression Media and Alarms over IP + Diallers.
This optional feature enables monitoring of the rack installation remotely over IP through IP Camera and Supportive Software.
